Automatic sink VLU 01

The VLU 01 automatic sink is a stainless steel sink equipped with a mixer with a handle and a sink with a sensor-controlled tap whose water temperature is set by a mixing valve. The water starts automatically as soon as the hands are within range of the sensor and goes out when the hands are removed. Water leaks for a short time after moving your hands out of sensor range – delay after washing your hands. The water closes automatically if the sensor is covered for more than 30 seconds. The drain is always located on the opposite side of the small sink. The basic version has a drain located on the right side (when viewed from the front of the sink). By order, it is possible to order it to be on the left side. VLU 01 is made of AISI 304 stainless steel. Other materials are available on request, eg AISI 316. With its construction, VLU 01 meets EU standards and is intended mainly for the food industry with a lack of space.

Variations:

VLU 01 – power supply 12V/50Hz from a ZAC transformer, left/right
VLU 01B – power supply 6V (4xAA), left/right

DELIVERY INCLUDES:

– sink, mixer with lever, washbasin, electronics, solenoid valve, angle valve with filters – 2 pcs, mixing valve, siphon, connecting hoses, small connecting material

SCHEME:

A – cold water input

B – warm water input

C – el. voltage

D – drainage

E – scanning
