AUM 015 is an AISI 304 stainless steel washbasin, automatically controlled by a sensor, suitable for wall mounting.
This sink is not equipped with a classic sensor faucet (tap), but is equipped with a resistant stainless steel spout with sensor contactless control. The sensor photocell responds when the hands are placed under the spout – water automatically begins to flow by opening the solenoid valve after the hands are placed in the scanning zone. The sink is equipped with a mechanism against overpressure. An integral part of the sink is a stainless steel mesh, which prevents various objects from falling into the siphon. A 6/4 “nipple is welded to it to connect the siphon or directly to the sewer.
The sink does not have a welded spout, but it is completely welded from 1.5 mm thick stainless steel, which makes it very resistant to damage. The inner edges are welded at 90˚. The sink can also be delivered without a tap. When ordering, it is important to specify whether the customer wants a wall-mounted faucet (without a hole in the sink) or a standing one (position of the hole in the sink for the faucet left or right).
AUM 015 – washbasin with drain, without faucet
AUM 015.E – washbasin with instantaneous electric heater (230 V)
Version with 12 V, 50 Hz power supply (with safety supply transformer ZAC)
AUM 015.1 – with 1 water supply
AUM 015.2 – hot and cold water connection
AUM 015.TV – with thermostatic valve
Version with 6V power supply (4xAA battery):
AUM 015.1B – with 1 water supply
AUM 015.2B – hot and cold water connection
AUM 015.TVB – with thermostatic valve
|Basic technical data:
AUM 015.1, .2, .TV (+ battery voltage version)
- Set the water supply according to the picture
- Install a 40 mm drain.
- Set el. cable – 12 V, 50 Hz from ZAC transformer (CYKY 2Ax1,5) – for power supply version 12 V
- For AUM 015.E, install the CYKY 3C 1.5-2.5 electric cable
A – cold water (AUM 015.2, .TV, .E), mixed water (AUM 015.1), internal pipe G 1/2″
B – warm water (AUM 015.2, .TV), internal pipe G 1/2″
C – el. connection
D – drainage
