Flushing system for urinals – AUP 2

The flushing system for urinals AUP 2 is controlled by a sensor (photocell) that responds to people (objects) entering the scanning zone. Upon leaving the scanning zone, the rinsing system is activated. The photocell of the sensor does not react to people passing by and is not sensitive to daylight or artificial light. After 24 hours of inactivity, the urinal rinses itself. The amount of water flow is adjusted by means of a ball valve.

AUP 2 is intended for use in public spaces where maximum user comfort while maintaining the maximum degree of hygiene and maximum water saving.

Basic technical information:

• Sensor radius 0 – 0.8 m
• water supply: 1/2 “
• water pressure: 0.1-1.0 MPa
• output: depending on the urinal
• adjustable rinsing time: 1-20 seconds (factory setting – 5 seconds)
• power supply: 12 V, 50 Hz
• power required: 6 VA
• power source:
  ZAC 1/20 (max. 3xAUP 2)
  ZAC 1/50 (max. 8xAUP 2)
• weight: 1.5 kg

Delivery includes:

• Built-in box
• Ul. and ex. screws
• Solenoid valve
• Stainless steel housing steel that includes an electronics box
• Ball valve
• Mounting spacer
• Cover metal box
• Fine connecting material

* – depending on the use of siphon

Conditions for erecting the structure

1. Place a niche 150x150x70 mm to install the AUP2 box
2. Place the 1/2 “water supply on the AUP 2 and on the urinal – as shown
3. Install a drain – depending on the siphon
4. Install electrical cables 1-12 V, 50 Hz from the safety power transformer ZAC

A – water supply, pipe 1/2”
C – el. cable CYKY 2Ax1.5
D – drainage (depending on the syphon)
E – scanning zone
