This Hygiene Barrier provides a fast and hygienic entrance to the workshop thanks to 3 brushes mounted vertically and 2 horizontally mounted brushes which are rotating mutually. Thanks to the integrated dosing pump, all brushes are sprayed with a mixture of water and detergent during operation. The working time of the brushes can be manually adjusted to 01-10 seconds. The operation is started and stopped with the sensors at the start and end points. This Hygiene Barrier  designed to provide a high degree of safety by the mandatory passing of personnel through all hygienic controls included mandatory hands disinfection program ensures the best cleaning of the shoe soles as well as disinfection for hands. It provides a fast and hygienic entrance to the workshop thanks to 3  vertically mounted brushes  and 2 horizontally mounted brushes which are rotating mutually. Thanks to the integrated dosing pump, all brushes are sprayed with a mixture of water and detergent during operation. The working time of the brushes can be manually adjusted to 01-10 seconds. The operation is started and stopped with the sensors at the start and end points.   Working Method and Properties To prevent the bristles from breaking off, the brushes are about 8cm above the rotating cylinders which are installed in depth. Thanks to the Integrated Dosing Pump, the solution consisting of a mixture of Water and Chemical cleaning agent is sprayed onto the brushes. You can also check the density of the cleaning agent through the nozzles. The working time of the brushes can be adjusted manually from the program, for 01 to 10 seconds or longer. Special Sensors at the starting points start the operation. This model has about 100cm long brushes. Rotating brushes are automatically activated by the sensors. The next step is hand disinfection and the last step is free passage through the turnstile. Thanks to the turnstile system and the automatic processing process, the staff enter the workshop serially, without waiting in line. The brushes on the system are long-lasting and resistant to breakage / spillage.   Product Benefits

• Working time of the brushes that clean the shoes / boots soles can be adjusted as desired.
• Brushes can be easily removed and installed without the need for an additional tool.
• With the special brushing system that penetrates deep into the floors, the floors are cleaned in a guaranteed way.
• Thanks to its deeply mounted brush bristles, it offers a long service life.
• A mandatory hand disinfection is provided simultaneously, the system does not operate with one hand, so it provides absolute disinfectant
• Hand disinfection time can be adjusted.
• The system, which does not allow manual intervention from the outside, guarantees a safe disinfection.
• In case of emergencies such as power cuts and “EMERGENCY STOP” button activation, the turnstile provides free passage in both directions.
• It is possible to open or lock the output direction according to preference.
• Our product has a quality and hygienic surface structure thanks to its Stainless Steel special Satin surface.

Machine Dimensions: 2750mm (length) x 1250mm (width) x 1750mm (height)

With the sink activated by the sensors at the knee level, water is prevented from wasting, so failure problems with mechanical or photocell faucets are also avoided. Water flows when the sink is stopped in front of the sink and the sensor detects the person, it stops when pulled, so it is the most reliable system. What does  EPSET Hygiene Barrier do? Our hygiene line with sink, mop and disinfectant turnstile provides a holistic hand washing and disinfection that effectively meets the hygiene standards of HACCP, BRC, IFS and NSF. The cleaning process includes extensive hand washing with soap and hand disinfection. For the transition to sensitive production areas, it ensures that only hand disinfection personnel are allowed with a tourniquet afterwards. With an automatic hand soap and disinfectant dispenser, our hand hygiene control solutions provide a convenient and cost-effective service. Working Method and Properties With the sink activated by the sensors at the knee level, water is prevented from wasting, so failure problems with mechanical or photocell faucets are also avoided. Water flows when the sink is stopped in front of the sink and the sensor detects the person, it stops when pulled, so it is the most reliable system. There is a solution mat for cleaning the soles of our hygiene turnstile, which is completely made of stainless steel. Pool solution is filled and drained automatically in the foot pool part of this mat. Thus, the foot pool can clean itself regularly. Operations such as filling or emptying are not required by an operator manually. With the automatic preparation of the solution Water and Chemical, the dosage can be determined optionally. Hand Disinfection and Hand Washing Thanks to the hand disinfection unit, disinfectant is applied automatically at the determined dosage, so that only people whose hands are properly cleaned can be entered into sensitive production areas. Thanks to the two-hand mandatory disinfection zone, it is a must to disinfect both hands at the same time and maximum hygiene is provided. The sink, liquid soap dispenser, paper towel holder and trash bin on the hygiene line allow the staff to wash their hands as they wish, ensuring hand sanitation. Turnstile turns freely in the direction of the Social Area from the Workshop and can be closed according to preference. In “power cuts” and “EMERGENCY” situations, the turnstile provides free passage in both directions. Product Benefits

•  Cleaning the soles of the shoes, washing the hands, disinfecting takes place in one step.
•  Sink, towel holder and trash can are placed for hand washing.
•  Standard MECHANICAL soap dispenser is offered, Photocell Soap Dispenser can be optional.
• Provides quick and efficient sanitation at the facility.
• Curly mop with chemical Solution inside provides deep cleaning of the sole of the feet.
• The foot pool chemical solution can fill and discharge automatically, thus saving labor and time, and maintaining contact-less hygiene conditions.
• A mandatory hand disinfection is provided for a mandatory 2 hands simultaneously, and the dose of the hand disinfectant can be determined.
• There is a turnstile lock that can be adjusted according to the exit direction and the preference, the turnstile time can be adjusted.
• 3 turnstile arms are stainless.
• Our product has a quality and hygienic surface structure thanks to stainless steel.
• The risk of infection and contamination is minimized.
• There is an emergency stop button for emergency escapes.
• There are ergonomic special Stainless ball Joint Feet that can be adjusted in height. 4mm diameter stainless steel railing is available.
• Machine Dimensions: 2150mm (length) x 1050mm (width) x 1700mm (height)



The SA ETG-70 boot and boot washing machine cleans both the soles and sides of shoes. Ensuring continuous access for personnel in accordance with hygiene standards, the system is an automatic, two-way hygiene barrier designed for thorough cleaning of the sides and soles of boots. The device, with two horizontally mounted, counter-rotating brushes and three vertically mounted brushes, ensures quick and hygienic access for personnel to the workshop or facility. The horizontal brushes can be easily removed and installed for daily cleaning and maintenance without requiring any additional tools. What is the Function of the SA-ETG-70 Hygiene Barrier with Hand Sanitizer, Sole, and Boot Wash? It ensures a hygienic entrance to the facility by cleaning the soles and sides of boots, and disinfecting hands. This machine allows your staff to proceed quickly and efficiently throughout the cleaning process. While the sides and soles of boots are thoroughly cleaned, it also provides the opportunity for hand disinfection. Based on a one-time walk-through cleaning principle, our machine provides fast and comprehensive sterilization with the option to clean the soles and sides of boots. This machine has the advantage of being placed in frequently used areas within the facility, such as at the entrances and exits of the workshop, to ensure the cleaning of shoes, making sanitation mandatory. Operating Principle and Features It operates with two horizontally mounted brushes and three vertically mounted brushes. The system is fully automatic and activated by sensors and valves. This process also prepares and releases the cleaning agent and water mixture. Boot sides and soles are cleaned in the following steps: Rotating side brushes move simultaneously to clean the sides of the boots, and horizontally rotating brushes move horizontally to clean the soles. A mixture of water and detergent is sprayed. The user moves forward to complete the cleaning of the soles and sides of the boots. The next step is hand disinfection, and the final step is the turnstile's ability to provide free passage. Hand Disinfection Our hygiene barrier machine is also equipped with a turnstile system with hand disinfectant. In addition to boot cleaning, you can also disinfect your hands. This makes hand disinfection a necessity, and those who have not properly disinfected are systematically denied entry. The hand disinfection unit automatically applies the specified dose of disinfectant, ensuring that only those with properly cleaned hands are allowed into sensitive production areas. The turnstile rotates freely at the exit from the production hall to the social area and can be closed if desired. In cases of "power outages" and "emergencies," the turnstile will allow free passage in both directions. Product Key Benefits The operating times of the brushes that clean the soles of the feet and the sides of the boots can be easily adjusted. The brushes can be easily removed and reattached without the need for any additional tools, making cleaning easy, fast, and extremely practical. The deeply mounted bristles ensure a long service life. Mandatory hand disinfection is simultaneously achieved, and since the system is not one-handed, it delivers complete disinfectant. The exit direction can be either open or locked, depending on your preference. Our product boasts a high-quality and hygienic surface thanks to its special satinized stainless steel surface. The risk of infection and contamination is minimized. Adjustable chemical dosing is available. A bypass entrance is available for those entering wearing shoes or slippers. It can be integrated with card, finger, and face recognition systems. It can be integrated with automatic doors.
